PINOFLEX

[Translate to English:]

Torsional flexible coupling with plug-in flexible elements composed by single pins

Technical Data

  • Torque Range TKN [kNm]
    1.32 kNm - 8.73 kNm
  • Speed range [1/min]
    1,650.00 RPM - 3,150.00 RPM

Application

  • High speed shaft of machinery driven by electric motor requiring a short installation length.

Efficiency

  • Plug-in design with minimum built-in length of the coupling
  • Possibility of removing the elastic elements without having to disconnect the machinery
  • High shock loads damping capacity

Tailor-made Solutions

  • Shaft to shaft or shaft to flange connection design available on request
  • Shaft to flywheel J620 SAE 8-14 inches available on request
  • Extra short installation design available on request

Design

  • Low number of components
  • Modular design of the elastic elements
  • Easy to install
